| Place of Origin: | Shanghai |
|---|---|
| Brand Name: | ZANFENG |
| Certification: | ISO9001 |
| Model Number: | CZ-V004S |
| Minimum Order Quantity: | 1 Piece |
| Price: | $20000/pieces or Negotiable |
| Packaging Details: | Standard Export Packing, Fumigation-free wooden cases. |
| Delivery Time: | 1-15 |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 5000 Set/ Month |
| Usage: | Home Elevators | Design Style: | Simple |
|---|---|---|---|
| Application: | Villa | Drive Type: | AC |
| Floor: | PVC Pattern | Machine Room: | Small Machine Room/machine Roomless |
| Material: | Stainless Steel | Rated Speed: | 1.0-4.0m/s |
| Control System: | VVVF Controller | Service: | OEM & ODM |
| Rear Wall: | Marble Pad Pasting, Blacktitanium Mirror Stainless Steel | ||
| High Light: | villa VVVF Passenger Elevator,Residential assenger Elevator,Indoor Home small passenger lift ODM |
||
Factory Direct Price elderly people smart villa elevator home
Stainless steel Manufacture Residential Indoor Home Lift Small Elevator
Spacious Space Taste Leisurely Life
The maximum net height of lift car can reach2200mm[roofheight: 3m),which can bring you open space experience and make you go in and out more easily.
Green and Noiseless Design Gives You Healthy Life
8 million-negative oxygen ion fan (optional)
The anion it releases is equivalent to that released by a big tree with the height of 5m.In the meantimeit can sterilize absorb methanolremoves peculiar smell&second-hand smoke and filters PM2.5 to make lift car filled with exceptional fresh air.
Equivalent to that released by Filters PM2.5 to make lift car
a big tree with the height of 5m filled with exceptional fresh air
Optional
| Machine room-less passenger elevator | ||||||||
| Load(kg) | NO.of persons | speed(m/s) | door opening type | opening size (width X high mm) |
net size (width X high mm) |
Hoistway net size (mm) | ||
| (width X high mm) | OH | PP | ||||||
| 630 | 8 | 1.0 | split door | 800 | 1300x1250 | 2100x1700 | 4500 | 1500 |
| 1.5 | 4600 | 1600 | ||||||
| 1.75 | 4700 | 1700 | ||||||
| 800 | 10 | 1.0 | 800 | 1400x1350 | 2200x1800 | 4500 | 1500 | |
| 1.5 | 4600 | 1600 | ||||||
| 1.75 | 4700 | 1700 | ||||||
| 1000 | 13 | 1.0 | 900 | 1600x1500 | 2400x2000 | 4500 | 1500 | |
| 1.5 | 4600 | 1600 | ||||||
| 1.75 | 4700 | 1700 | ||||||
| 1150 | 15 | 1.0 | 1000 | 1750x1500 | 2600x2000 | 4500 | 1500 | |
| 1.5 | 4600 | 1600 | ||||||
| 1.75 | 4700 | 1700 | ||||||
| Small machine room passenger elevator | ||||||||||
| Load(kg) | NO.of persons | speed(m/s) | door opening type | opening size (width X high mm) |
net size (width X high mm) |
Hoistway net size (mm) | machine room size(mm) | |||
| (width X high mm) | OH | PP | width X high mm |
MR.H | ||||||
| 630 | 8 | 1.0 | split door | 800 | 1300x1250 | 1900x1900 | 4400 | 1400 | 1900x1900 | 2300 |
| 1.5 | 4500 | 1500 | ||||||||
| 1.75 | 4700 | 1600 | ||||||||
| 800 | 10 | 1.0 | 800 | 1400x1350 | 2000x2000 | 4400 | 1400 | 2000x2000 | ||
| 1.5 | 4500 | 1500 | ||||||||
| 1.75 | 4600 | 1600 | ||||||||
| 1000 | 13 | 1.0 | 900 | 1600x1500 | 2200x2200 | 4400 | 1400 | 2200x2200 | ||
| 1.5 | 4500 | 1500 | ||||||||
| 1.75 | 4600 | 1600 | ||||||||
| 1150 | 15 | 1.0 | 1000 | 1750x1500 | 2300x2200 | 4400 | 1400 | 2300x2200 | ||
| 1.5 | 4500 | 1500 | ||||||||
| 1.75 | 4600 | 1600 | ||||||||
Green and Noiseless Design Gives You Healthy Life
Equivalent to that released by Filters PM2.5 to make lift car
The anion it releases is equivalent to that released by a big tree with the height of 5m.In the meantimeit can sterilize absorb methanolremoves peculiar
smell&second-hand smoke and filters PM2.5 to make lift car filled with exceptional fresh air.
The application of a series of intelligent technologies to Tenau villa not only brings you comfort but also health.
| lnformation Display | |
| Hall and car digital position indicator | Running number display |
| Hall and car call/register | Floor display character arbitrary setting |
| Hall and car running direction display | |
| Steady Running | |
| Return to base station without call | Pre-torque output |
| Full collective control | Upon elevator floor setting |
| Independentservice | Hoistway self-learning |
| Full-load direct running (LNS] | End station for speed and floor number correction |
| Automatic door switch | Parking |
| Passenger Comfortability | |
| Hall and car door setting time | Bypassed stop setting |
| 0pen and close button | lnput port evaluation |
| Automatic ventilation and lighting ofautomatic control in car | Manualty selected floor |
| Cancellation of wrong landing | |
The application of a series of intelligent technologies to Tenau villa not only brings you comfort but also health.
We offer a contactless button, push button, COP, LOP , hall lantern , segment ,dot matrix , LCD and TFT displays etc.
FAQ
1. What can I get the quotation?
Within 24 hours the inquiry will be reply.If you are very urgent the price,
pls call us or tell us your email so that we will regard your inquiry priority.
2. How can i get a sample to check your quality?
Provide our existing sample to check our quality,the shipping cost need to paid by you.After price confirmation,you can
require for samples to check our quality,but sample cost need to paid by you.the sample cost can be refundable if you bulk order quantity reach our request.
3. What kind of files do you accept for printing?
PDF, Adoble Illustrator, CDR
4. Can you do the design for us?
Yes. We have a professional designing team,just tell us your details and we will help to carry out your idrars into perfect products.it's also ok if you do not have the complete files.Sent us high resolution images,we can design the layout you want.
If you send your LOGO to us,we will make the artwork for you reference.
Should you have any question ,pls do not hesitate to contact me.
